| Years | Axle Type | Length | Width | Cab-To-Axle | Runners |
|---|---|---|---|---|---|
| 2002 – Older | Single Wheel Short Wheel Base Single Wheel Long Wheel Base Dually |
84″ 8′ 6″ 8′ 6″ |
84″ 84″ 97″ |
40″ 56″ 56″ |
38″ 38″ 38″ |
| 2003 – Present | Single Wheel Short Wheel Base Single Wheel Long Wheel Base Dually Mega Cab Dually |
84″ 8′ 6″ 8′ 6″ 84″ |
84″ 84″ 97″ 97″ |
38″ 58″ 58″ 38″ |
42″ 42″ 42″ 42″ |
| 2007 – Present | Single Wheel Cab & Chassis Cab & Chassis (60″ C/A) Cab & Chassis (84″ C/A) |
9′ 4″ 9′ 4″ 11′ 4″ |
84″ 97′ 97″ |
60″ 60″ 84″ |
34″ 34″ 34″ |
Quick Reference for
Ordering 903 Truck Beds
Terminology
- Length: Measurement from cab to end of frame
- Width: Measurement from outside of tire to outside of tire
- CA: Measurement from cab to center of axle
- Runner: Measurement from outside of frame to outside of frame at the rear of the frame.
Order Method
Length x Width x C/A x Runner
Example: SD 8’6″ L x 97″ W x 60″ CA x 34″ Runners (then add options)
